Flywoo GOKU GN405 F4 2-6S 16x16 Stack/Combo (F4 FC / 35A 8Bit 4in1 ESC)

Flywoo GOKU GN405 F4 2-6S 16x16 Stack/Combo (F4 FC / 35A 8Bit 4in1 ESC)

$89.99 - $89.99
$89.99
$89.99 - $89.99
$89.99
In Stock
Pre Order
Coming Soon
Free Delivery on U.S.A. Orders $99 or more

Add To Wishlist

Unleash the power of your drone with Flywoo's GOKU GN405 Nano 35A STACK! This tiny, but powerful flight controller is packed with features, such as a barometer, 16MB blackbox, 6 serial ports, I2C functionality and WS2812 LEDs.  All these amazing features on 16x16mm platform with this Flywoo stack!

Check out all our 16x16 stacks, and our Flywoo gear selection!

Features

  • F405 BGA MCU
  • Barometer
  • 5V 2A BEC
  • Black Box 16MB
  • 6 UARTS
  • WS2812LED

Specifications

GOKU GN405 Nano 16x16 FC

  • MCU: STM32F405 BGA
  • IMU: ICM42688
  • Barometer: DPS310
  • input voltage: 2-6S
  • Onboard LED: WS2812x4
  • 6 hardware UARTS (UART1,2,3,4,5,6)
  • Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only.
  • PPM and PWM receivers are not supported.
  • Onbord 16Mbytes for Blackbox logging
  • 5V Power Out: 2.0A max
  • 3.3V Power Out: 0.5A max
  • Dimensions: 22x22mm
  • Mounting Holes: Standard 16/16mm square to center of holes
  • Weight: 2.3g
  • Firrmware : FLYWOOF405NANO
BS35A BLheli_S 2-4S 4in1
  • Weight: 2.5g
  • Mounting Hole: 16x16mm (M3)
  • Input voltage: 2-6S
  • Support Oneshot, Multishot,  DShot150/300/600

Includes

  • 1x Flywoo GOKU GN405 F405 Nano 2-6S AIO 16x16 Flight Controller w/ 35A 8Bit 4in1 ESC

>
