Eachine NANO VTX V2 25-400mW 5.8GHz Micro VTX - U.FL

$13.99
In Stock
Pre Order
Coming Soon
Free Delivery on U.S.A. Orders $60 or more
Add to Wishlist

Eachine NANO V2 VTX is features stable output power, long transmission distance and strong power filter. It can ensure that the image has no snowflakes or stripes under the maximum throttle situation. It features a tramp interface for remote configuration through Betaflight OSD, as well as a button interface. It won't interfere with other pilots when powering on, and supports 8 people flying at the same time.

Check out all our Micro/Nano VTXs, and all our Eachine gear!

Features

  • 5.8GHz 48CH FPV transmitter
  • 5V input voltage
  • 25/100/200/400mW power switchable
  • 5.8G ISM band
  • 1-2km long transmission distance
  • Support OSD configuring via Betaflight flight controller
  • Support microphone
  • Support 8 drones flying at the same time without interference
  • It can ensure that the image has no snowflake, no stripes under the maximum throttle situation.

Specifications

  • Frequency: 5.8GHz 6 bands, 48 channels
  • Input Voltage: DC 5V
  • Output Power: PIT/25mW/100mW/200mW/400mW switchable
  • Control Mode: BFOSD Control(RX)/Button
  • Video System: NTSC/PAL
  • Antenna Interface:IPEX
  • Size: 15mm x 14mm x 4mm
  • Weight: 3g
Output Power
  • 5V/PIT@75mA
  • 5V/25mW@270mA/14dBm
  • 5V/100mW@350mA/20dBm
  • 5V/200mW@450mA/23dBm
  • 5V/400mW@530mA/26dBm
Frequency Table(Mhz):

Includes

  • 1x Eachine NANO V2 VTX Micro 25-400mW VTX - U.FL
