Description

The HGLRC Hammer Mini V2 is a small antenna suitable for lightweight 2–4" freestyle drones or 5" racing drones. The antenna is designed for the 5.8GHz band. With a gain of 2.5 dBi, it provides a good balance between range and directionality. With a weight of 1.5 grams, the antenna is also suitable for lightweight drones where every gram matters.

Check out all our VTX Antennas and our collection of HGLRC products!

Features

• Optimized for 5.8 GHz FPV with RHCP polarization for clearer, more stable video
• Lightweight and compact design
• ~2.5 dBi gain provides a solid balance of range and omnidirectional coverage
• Durable radome housing helps protect against crashes and everyday wear

Specifications

• Frequency Range (MHz): 5000-6000
• Polarization: RHCP
• Gain (dBi): 2.5db
• Input Impedance (Ω): 50
• VSWR (5850MHz): ≤3.67
• Maximum Input Power (W): 50
• Connector Type: IPEX
• Radome Material: ABS
• Radome Color: Black
• Antenna Dimensions: Total length 130mm（rigid tube length 60mm, including connector cable length 55mm）
• Weight: 1.5g

Includes

• 1x HGLRC Mini Hammer Antenna V2 - RHCP
