Description

The AIKON AK8 80A 2-8S BLHeli_S ESC is a high-performance speed controller built for demanding FPV drone setups. Designed with high-grade MOSFETs for efficient current delivery, it supports DShot, Multishot, and OneShot protocols for smooth throttle response and reliable performance. Powered by BLHeli_S firmware, it ensures low latency, stable flight, and precise motor control—perfect for freestyle and racing drones.

Make sure to check out our other ESCs and entire line of Aikon gear!

Features

• Improved heat dissipation for higher efficiency and cooler operation
• 40V low-resistance MOSFETs for efficient power delivery
• Integrated CNC-machined top and bottom heat sinks
• Designed for demanding FPV drone applications
• High power output in a compact form factor
• Durable and cost-effective design
• Supports 3–8S LiPo input

Specifications

• ESC Protocols: DSHOT300 / DSHOT600
• MOSFET: High-performance MOSFET
• Burst Current: 100A (10 seconds)
• Dimensions: 26mm x 42mm
• Current Sensor Scale: 200
• Continuous Current: 80A
• MCU: EFM8BB21F16G
• Power Input: 3–8S LiPo
• Firmware: C_H_40 24k
• ESC Telemetry: No
• Mounting: N/A
• Weight: 32g

Includes

• 1x AIKON AK8 80A 2-8S BLheli_S ESC
• 1x 50V 1000UF Capacitor
• 2x Power Cable - 200mm
• 1x Signal Wire - 200mm
