AIRCRAFT

• Takeoff Weight: Approx. 160 g
• Dimensions: 167×171×54 mm (L×W×H)
• Max Ascent Speed:

  • 0.5 m/s (Cine mode)
  • 3 m/s (Normal mode)
  • 5 m/s (Sport mode)
• Max Descent Speed:

  • 0.5 m/s (Cine mode)
  • 3 m/s (Normal mode)
  • 3 m/s (Sport mode)
• Max Horizontal Speed:

  • 8 m/s (Cine mode)
  • 12 m/s (Normal mode)
  • 12 m/s (Sport mode)
• Max Takeoff Altitude: 2000 m
• Max Flight Time: Approx. 19 minutes (approx. 17 minutes with the propeller guards)
• Max Hovering Time: Approx. 18 minutes (16.5 minutes with the propeller guards)
• Max Flight Distance: 7 km
• Max Wind Speed Resistance: 10.7 m/s (Level 5)
• Operating Temperature: -10° to 40° C (14° to 104° F)
• Global Navigation Satellite System: GPS + Galileo + BeiDou
• Internal Storage: 49 GB
• Class: C0 (EU)

CAMERA

• Image Sensor: 1/2-Inch CMOS Sensor
• Lens:

  • FOV: 119.8°
  • Format Equivalent: 16.5 mm
  • Aperture: f/2.2
  • Focus: 0.7 m to ∞
• ISO Range:
  • Photo: 100-3200 (Single Auto), 100-12800 (Burst Auto/Timed Auto), 100-12800 (Manual)
  • Video: 100-12800 (Auto), 100-12800 (Manual)
• Shutter Speed: Video: 1/8000-1/30 s, Photo: 1/8000-1/10 s
• Max Image Size: 12MP Photo, 4000×3000 (4:3), 4000×2250 (16:9)
• Photo Format: JPEG
• Video Resolution:

  • Horizontal Shooting:

    • 4K (4:3*): 3840×2880@60/50/30fps

    • 1080p (4:3*): 1440×1080@60/50/30fps

    • 4K (16:9): 3840×2160@100**/60/50/30fps

    • 1080p (16:9): 1920×1080@100**/60/50/30fps
  • Single Lens Mode:

    • Vertical Shooting:

    • 2.7K (9:16): 1512×2688@60/50/30fps

    • * Recording in 4:3 aspect ratio is only supported when connected to
    • DJI Goggles.
      ** 4K/100fps and 1080p/100fps recording are only supported when using motion control or remote control
• Video Format: MP4
• Max Video Bitrate: 80 Mbps
• Color Mode: Normal
• EIS:
  • Supports RockSteady and turning stabilization off*.

  • * The stabilization switch (On/Off) is only available when paired with goggles. When stabilization is turned off, footage captured supports offline stabilization with Gyroflow.
• Supported File System: exFAT

GIMBAL

• Stabilization: 2-axis mechanical gimbal (tilt, roll)
• Mechanical Range: Tilt: -125° to 105°, Roll: -43° to 43°
• Controllable Range: Tilt: -90° to 70°
• Max Control Speed (tilt): 100°/s
• Angular Vibration Range: ±0.01°
• Image Roll Correction: Supports correction of footage recorded on the drone. Live view correction is unavailable only when using with goggles.

VIDEO TRANSMISSION

• Video Transmission System: DJI Neo 2 Digital Transceiver (O4)
• Live View Quality: Up to 1080p/60fps
• Operating Frequency:

  • 2.400-2.4835 GHz

  • 5.170-5.250 GHz

  • 5.725-5.850 GHz

  • Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
• Transmitter Power (EIRP):
  • 2.4 GHz:

    • < 26 dBm (FCC)

    • < 20 dBm (CE/SRRC/MIC)
  • 5.1 GHz:

    • < 23 dBm (CE)
  • 5.8 GHz:

    • < 26 dBm (FCC)

    • < 26 dBm (SRRC)

    • < 14 dBm (CE)
• Communication Bandwidth: Max 60 MHz
• Max Transmission Distance (unobstructed, free of interference):

  • FCC: 10 km

  • CE: 6 km

  • SRRC: 6 km

  • MIC: 6 km
• Max Transmission Distance (unobstructed, with interference):

  • Strong Interference: Urban landscape, approx. 1.5-3 km

  • Medium Interference: Suburban landscape, approx. 3-6 km

  • Low Interference: Suburb/seaside, approx. 6-10 km
• Max Transmission Distance (obstructed, with interference):

  • Low Interference and Obstructed by Buildings: Approx. 0-0.5 km

  • Low Interference and Obstructed by Trees: Approx. 0.5-3 km
• Max Video Bitrate: 60 Mbps
• Max Download Speed: Wi-Fi: 80 MB/s
• Antennas: 2 Antennas, 1T2R

BATTERY

• Capacity: 1600 mAh
• Weight: Approx. 46 g
• Nominal Voltage: 7.16 V
• Max Charging Voltage: 8.6 V
• Battery Type: Li-ion
• Energy: 11.5 Wh
• Charging Temperature: 5° to 40° C (41° to 104° F)
• Charging Time:

  • When Using the Two-Way Charging Hub (65W max charging power): Approx. 68 minutes to charge three batteries simultaneously from 0% to 100%
  • When Directly Charging the Aircraft Body (15W max charging power): Approx. 70 minutes to charge from 0% to 100%

BATTERY CHARGING HUB

• Input:
  • 5 V, max 5 A
  • 9 V, max 5 A
  • 12 V, max 5 A
  • 15 V, max 4.33 A
  • 20 V, max 3.25 A
• Output (charging): 5V, 2A
• Charging Method: 3 batteries charged simultaneously
  The number of batteries that can be charged simultaneously depends on the power of the charger used. Using a charger rated above 45 W allows you to charge three batteries at the same time. Using a charger rated between 30 W and 45 W allows you to charge only two batteries simultaneously. Using a charger below 30 W will charge the batteries sequentially, from the highest remaining charge to the lowest. Refer to the charging protocols supported by the charger.
• Compatibility: DJI Neo 2 Intelligent Flight Battery

WI-FI

• Protocol: 802.11 a/b/g/n/ac/ax
• Operating Frequency: 2.400-2.4835 GHz, 5.170-5.250 GHz, 5.725-5.850 GHz
• Transmitter Power (EIRP):

  • 2.4 GHz:
    < 20 dBm (FCC/CE/SRRC/MIC)
  • 5.1 GHz
    < 23 dBm (CE)
  • 5.8 GHz:
    < 26 dBm (FCC/SRRC)
    < 14 dBm (CE)
• Effective Operating Range: 500m

BLUETOOTH

• Protocol: Bluetooth 5.2
• Operating Frequency: 2.400-2.4835 GHz
• Transmitter Power (EIRP): < 10 dBm

DJI RC-N3 REMOTE CONTROLLER

• Max Operating Time:

  • Without charging any mobile device: 3.5 hours
  • When charging a mobile device: 1.5 hours
• Operating Temperature: -10° to 40°C (14° to 104°F)
• Charging Temperature: 5° to 40°C (41° to 104°F)
• Charging Time: 2 hours
• Charging Method: 5 V, 2 A
• Battery Capacity: 2600 mAh
• Weight: Approx. 320 g
• Dimensions: 104.2×150×45.2 mm (L×W×H)
• Operating Frequency:

  • 2.400 GHz to 2.4835 GHz
  • 5.170 GHz to 5.250 GHz
  • 5.725 GHz to 5.850 GHz
• Transmitter Power (EIRP):
  • 2.4 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
  • 5.1 GHz: < 23 dBm (CE)
  • 5.8 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 30 dBm (SRRC)
