Description

The Flat Rats V2 t-mount motor by Ethix takes a twist off the previous model but adds a little more power and comes in a unibell design. This motor has a high KV, but is still smooth enough to help capture buttery cinematic footage on a 3” cine frame! The Flat Rats V2 t-mount motor has more power to give you better control and stability in small frames.

Check out our other motors, or the rest of out TBS Products!

Ethix Flat Rats also available with a 5mm shaft!

Features

• Higher KV Winding

• Unibell design

• 6S Capable

Specifications

• Stator Size (Diameter): φ15mm

• Kv: 2800

• Magnets N52SH: Curved

• Windings: 13.5 turns DLRK

• Shaft Length (mm): T mount

• Shaft Diameter (mm): 1.5mm

• Shaft material: steel

• Bearing: 4x2x2.5

• Weight (With Wires) (g): 15.5g

• Cells (Lipo): 6S

• Max Current (A): 15A

• Max Burst Current (A): 20A

• Internal Resistance (Rm): 0.23mΩ

• Wire Spec (AWG): AWG 24#

• Base Mounting Pattern: 12x12mm

• Base Mounting Thread: M2 Thread

• Motor Overall Dimensions: φ19.8mmx17.5mm

Includes

• 1x Ethix Flat Rats V2 1507 2800KV T-Mount Motor (1.5mm Shaft)
