Description

The FlyFishRC Tony 5 is a lightweight, durable frame created to make building a sub-250g 5-inch drone a possibility. The straightforward and easy-to-build platform is fully O4-ready and equipped with CNC aluminum camera plates to ensure your valuable camera remains maximally protected during all types of crashes.

Check out our other 5" frames as well as the rest of our FlyFishRC products selection!

Features

• Only 57g (w/TPU)
• Sub-250g capable
• High-end T700 carbon fiber
• 12.9-grade strength hardware with Loctite threadlocker pre-applied
• CNC aluminum camera plates
• Silicone shock-absorbers for O4 AU
• Compatible with both 19/20mm cameras
• Compatible with most VTX
• Compact body, well-suited for freestyle

Specifications

• Model: Tony 5
• Geometry: True-X
• Wheelbase: 215mm
• Arm thickness: 4mm
• Top plate thickness: 2mm
• Middle plate thickness: 2mm
• Bottom plate thickness: 2mm
• Propeller size: 5"
• CNC plate thickness: 4mm
• FPV cam spacing: 19mm/20mm
• Weight: 57g (with TPU parts)
• Total Dimensions: 133.7mm x 168 x 29mm
• Motor mounting hole: 12mm x 12mm (M2)
• Stack mounting holes: 20mm x 20mm / 25.5mm x 25.5.5mm(M3)
• VTX mounting holes: 20mm x 20mm / 25.5mm x 25.5mm(M2)
• Motor mounting holes: 12 x 12mm(φ2mm)

Links

Includes

• 1x FlyFishRC Tony 5 O4 Pro Sub250 Freestyle Frame Kit
