Foxeer Mega HD O3 Deadcat 3.5" Micro Frame Kit

Foxeer Mega HD O3 Deadcat 3.5" Micro Frame Kit

$61.49
$61.49
Add To Wishlist
View full details

Details

Description

The Foxeer Mega HD O3 3.5" Frame Kit provides a strong, light and robust frame for your drone. The kit includes its own high-quality canopy, battery straps, motor mounts and propeller guards, so you can build a powerful and reliable FPV drone quickly and easily. This frame was designed for maximum performance and durability, so you can enjoy a great FPV experience. The deadcat design makes the perfect frame for HD systems like the O3 Air Unit!

Check out the rest of our 3.5" frames and our entire Foxeer Collection!

Features

  • High quality Japan Toray T700 carbon fiber
  • Aluminum alloy 7075 CNC camera cage
  • O3/Analog/Vista/HDzero/Walksnail Compatible

Specifications

  • Material: Toray T700 carbon with a silky coating
  • Wheelbase: 166mm
  • Prop Size: 3.5"
  • Stack Mounting: Middle: 25.5mm M2; Rear:20x20mm/25.5x25.5mm M2
  • System: Analog, Vista, HDZero, Walksnail, fits O3 with included TPU prints
  • Motor Mounting Pattern: 12x12mm
  • Camera size: 19x19/20x20mm
  • Weight: 85g (Including TPU and screws)

Includes

  • 1x Foxeer Mega HD O3 Deadcat 3.5" Frame Kit
  • 1x 2mm Top Plate
  • 1x 2mm Center Plate
  • 1x 2mm Bottom Plate
  • 1x CNC Side Plate
  • 1x M3 x Φ5 x 20 Standoff
  • 1x SMA Antenna Mount
  • 1x Bottom Plate Front Protective Mount
  • 1x M5 Gopro Mount
  • 1x Arm Guard
  • 1x Rx Antenna Mount
  • 1x Isolation Column
  • 1x DJI O3 VTx Mount
  • 1x UFL Antenna Mount
  • 1x Cam Spacer
  • 1x M5 Nut
  • 1x M5x20 Screw
  • 1x Battery Anti-slip
  • 1x 225x15mm Battery Strap

More Info

  • SKU: FOXE-FR1214##3_5_INCH
  • Barcode: 641606519574


Overall rating: 4.0 / 5 from 4 reviews.

AI Generated Review Summary

Summary topics

Review topics: ["frame","drone"].

Review highlights

Reviews

Awesome frame

"Chose this frame because I wanted a 3. 5” that I could run an 03 air unit with no props in view. This was a perfect choice, I knew it was going to to be heavy but I was building a powerhouse. I went with 3600kv 2105 rcinpower motors on 4s and 6s with a motor limit. It flies great!! I like the fling ability with the weight . . it’s 292 grams without battery. Absolutely nasty on 6s 1300mah. I will carry a full size GoPro 10 but you feel the weight."

— joshua k. (5/5)

"Perfection"

— Rob (5/5)

Awesome little drone

"Love this frame so far"

— Carson T. (5/5)

Looks Great on First Look but...

"I was looking for a good 3.5" frame that would fit the O3 Air Unit and foolishly bought this. While there is PLENTY of room to mount a 20x20 stack in the middle it is only drilled for a 25.5x25.5 AIO type board. Looking at the bottom and middle plates you can see slotted holes that I was just certain were for 20x20 to 30x30 stacks so I thought for sure they could be used for that and was pretty excited to see a frame that could use pretty much any FC/ESC configurations. Nope, not even close. Who knows what they intended those slotted holes to be used for, but they won't fit a 20x20 nor a 30x30, so you have 4 slotted holes that are worthless and if one were to try to drill their own holes for a stack, these slotted things interfere and make that impossible. The ONLY thing you can mount in this frame is an AIO board. Horribly bad design for a frame this size that is plenty big enough for any stack or AIO combination. First and now last time I ever buy a Foxeer product."

— Brent (1/5)
