Description

The GEPRC SPEEDX2 2407E Motor - 1750KV is engineered for high-performance flight, offering rapid response and precision control. With an optimized rotor-stator gap, this motor is built for pilots who demand fast, efficient power delivery. Its sleek all-black design is complemented by a cut-out structure that improves airflow and heat dissipation.

Check out all our motors and our GEPRC selection!

Features

• All-black glossy finish with extensive cutouts for improved heat dissipation
• Precision CNC machining ensures tight tolerances and long-term reliability
• Lightweight and durable 7075 aerospace-grade aluminum construction
• Optimized for seamless freestyle and high-performance flying
• Reduced rotor-stator gap for ultra-responsive control

Specifications

• Model: SPEEDX2 2407E Motor
• KV: 1750
• Max Watt: 972.7W
• Peak Current: 49A
• Interphase Resistance: 38mΩ
• Propeller: 5-6inch
• Magnet: N52H
• Bearing: NMB/NSK
• Stator Configuration: 12N14P
• Dimension: ф34 x 30mm
• Shaft Diameter: ф5mm
• Shaft Length: 13.5mm
• Mounting Hole Size: 16 x 16mm
• Wire Specification: 20AWG/150mm
• Compatible ESC: 60A/6S
• Input Voltage: 6S
• Winding: Single-strand copper winding
• Color: Black
• Weight: 39g (including wire)
• Compatible Models: Suitable for 5inch - 6inch racing FPV quads

Includes

• 1x GEPRC SPEEDX2 2407E Motor - 1750KV
