HappyModel EX 0802 19000Kv Whoop/Micro - CW

HappyModel EX 0802 19000Kv Whoop/Micro - CW

$10.99
$10.99
Add To Wishlist
View full details

Details

Description

Great motor for any whoop and a perfect replacement part for the Happymodel Mobula 6 HD.

We also carry these motors in multiple KV options.

Check out the rest of our Mobula 6 parts & accessories and all our Happymodel gear!

Features

  • The lightest 0802 brushless motors around the world only 1.7g
  • Double E-clip design, prevent Motor bell to flying off
  • Good Dynamic balance

Specifications

  • KV: 19000Kv
  • Shaft Diameter: 1.0mm
  • Configuration: 9N12P
  • Stator Diameter: 8mm
  • Stator Length: 2mm
  • Motor Dimension(Dia.*Len): Φ10.5mm*14.9mm
  • Terminals: JST1.25mm
  • No.of Cells(Lipo): 1S LiPo
  • Wire length(include connector): 27mm
  • Weight: 1.7g

Includes

  • 1x Happymodel EX0802 19000Kv Whoop/Micro Motor for Mobula 6 HD - CW

More Info

  • SKU: 691023509856
  • Barcode: 691023509856


Overall rating: 4.78125 / 5 from 32 reviews.

AI Generated Review Summary

The HappyModel EX 0802 19000Kv Whoop/Micro - CW motor is highly praised for its perfect size and efficiency, making it an ideal replacement for HD Mobula6 motors.

Summary topics

  • Product Size: 19%
  • Replacement Value: 28%

Review topics: ["size","weight","replacement","works","motors","flight"].

Review highlights

  • "Good combo motors and size of wires are perfect" — Joel T.
  • "Direct replacement perfect size Weight" — jimmy s.
  • "Light-weight, sturdy motors, good size." — Tuan N.

Reviews

Happymodel 802 19000kv

"A little disappointed the motor went out on me.I guess I got a bad batchard times, I hope they see this review and work something out with me and sand send me a motor for being good customer"

— Luis V. (5/5)

good

"seller: good, prompt, no complaints. product: does seem to be an upgrade over the same kv SE 0802 motors. starts spinning with slightly less throttle compared to the SEs. I have them (EX and SE 0802 19000kv motors) mix and matched and the quad is flying just fine."

— Jonathan G. (5/5)

Perfect for UWL builds. Wish

"Perfect for UWL builds. Wish it had a 1.5mm shaft for durability though"

— Mathew S. (4/5)

Some of the best 802 motors

"I have these on a few quads. They are still going strong after two years. Just bought some for a UWL whoop and these new ones reminded me how smooth they are. Definitely recommend"

— Andrew K. (5/5)

Ok but not good

"One of the magnets came off during inspection after 1 flight, poor Quality Control"

— Magnus T. (3/5)

If you want to get

"If you want to get high quickly, these are the motors for you."

— Sean M. (5/5)

Great motors

"I already have a set on my micro and love them, so I bought a set for backup/replacement."

— Wolf D. (5/5)

Good combo motors and size

"Good combo motors and size of wires are perfect"

— Joel T. (5/5)

This is not my first

"This is not my first time buying these motors and I love them."

— Brian S. (5/5)

Excellent v2 motor from Happymodel

"Excellent motor - the best 0802 Happymodel ever made. Gobs of power and no annoying sound, like with the older generation of motors. So good!"

— John S. (5/5)

Q&A

do you have these 0802 happy model bell top motors for mobula6 hd in CCW? I have a single over heating motor on the rear right corner... swapped it to the front left and it is definatelt overheating and loosing power so I just need a single motor but all I see on your site is CW. thanks
Motor's are no longer made in CW or CCW fashion, the direction is controlled through the esc using the BL-Heli Configurator.
