Details
Description
The HGLRC Draco A2 Night Vision Air Unit is part of the revolutionary Draco FPV HD VTX System. It delivers a stunning 1080p@60fps live feed with approximately 60ms latency and an outstanding transmission range of up to 15km. The Draco HD VTX system is one of the core products of the open-source Artlynk HD VTX system, which is committed to a collaborative and standardized network of components from different brands.
Checkout our VTX section and our full collection of HGLRC products!
Features
- ArtLynk Protocol: A low-latency, long-range communication protocol for drones, offering superior stability and range over traditional analog VTX.
- High-Definition Video Transmission: 1080p @ 60 FPS
- Wide‑Angle Clarity: 1/1.8-inch lens sensor and 160° FOV for a crisp, immersive live view.
- Low-Light Performance: Enhanced night vision for clear view in low-light conditions.
- Reliable Ultra-Long Range Transmission: Delivers smooth video with ~60ms latency and up to 15km range.
- Wide-Voltage Power: Supports 8-30V (2-6S LiPo)
- Comprehensive OSD Data: Supports MSP OSD data for BF/INAV with customization of real-time data content and layout.
Specifications
- Resolution: 1080p
- Frame Rate: 60fps
- FOV: 160°
- Communication Frequency: 5.8GHz
- Power Supply: 8-30V(2-6S)
- Tx Power: <33 dBm (FCC)
- Air Unit Interface: SH1.0-6pin
- Mounting Pattern: 20mm/25.5mm
- Antenna: Dual Transmit - Dual Receive
- Dimensions: 32x32x10mm
- Weight: 36g
Links
Includes
- 1x HGLRC Draco HD FPV VTX A2 Air Unit
- 1x A2 Enhanced Night Vision Camera
- 2x HGLRC Long-Range Antenna
- 2x SH1.0-6pin Cable
More Info
- SKU: G24554CN1Z
- Barcode: 723326380594
