Description

Experience enhanced reliability and performance with the iFlight Borg 60RS 60A 4-8S BLHeli_32 4-in-1 ESC, tailored for the demands of competitive racing. The new ESCs feature an integrated anti-spark filter, providing protection against voltage spikes that can damage your equipment. Designed with high polymer capacitors, this ESC eliminates the need for external capacitors in 5-inch racing models, simplifying installation and reducing weight. With BL32 firmware, STM32G071 MCU, Bidirectional DShot, telemetry, and full protocol support, the Borg 60RS ensures precise throttle response and maximum control.

Check out all our 20x20 ESCs and all our iFlight gear selection!

Features

• Support 4- 8S Battery Input for versatile power options.
• 8-Layer 3OZ PCB allows for continuous current handling of 60A, with a peak current of 65A.
• Integrated Anti-Spark Filter protects your equipment from voltage spikes.
• Built-in High Polymer Capacitors eliminate the need for external capacitors in racing models.
• FPC Ribbon Cable Connection ensures a more reliable link between the flight controller and ESC.

Specifications

• Protocol: Supports DShot150/300/600, MultiShot, OneShot, etc
• Input Voltage: 4-8S; Support LIHV battery
• Max. Continuous Current: 60A
• Max. Burst Current: 65A (10s)
• MCU: STM32G071N
• Driver: FD6288
• Firmware: BL32 (32bit ESC)
• Target: IFLIGHT_BLITZ_G3 32.9
• Current Sensor: No
• BEC: No
• Telemetry: Supported
• Bidirectional DSHOT: Supported
• Dimensions: 45 x 35mm±1
• Mounting Holes: 20 x20 mm/Φ4mm
• Weight: 14.1g±1

Includes

• 1x iFlight Borg 60RS 60A 4-8S BLHeli_32 4-in-1 ESC
• 1x Cables Set
• 4x Silicon Grommets
