With the extreme range and high packet rate of the iFlight ELRS Nano 2.4GHz Receiver and 160mm Antenna, failsafes are a thing of the past. The ExpressLRS RX Nano modules were developed in close cooperation with the ExpressLRS Team, with firmware targets already released.
Check out the rest of our RC receivers and all our RC transmitters, modules, and accessories!
Features
- Improved circuit design
- Upgraded Temperature Compensated Crystal Oscillator (lower packet loss, high frequency stability)
- High-performance at 2.4GHz signal has outstanding performance and long-range capabilities
Specifications
- Antenna connector: IPEX
- Firmware: ExpressLRS iFlight 2.4GHz Nano RX
- Frequency bands: 2.4GHz ISM
- Telemetry Power: 12.3dbm（17mW 2.4GHz）
- Dimension: 10x13mm
- Connector: SUR0.8 Connector
- Interface: RX TX 5V GND
- Input voltage: 5V
- Protocol: CRSF
- Weight: 0.5g
Includes
- 1x iFlight ELRS Nano 2.4GHz Receiver
- 1x 160mm Antenna
More Info
- SKU: 23749
- Barcode: 723326377839
