iFlight Blitz F411 1S 5A Toothpick/Whoop Flight Controller w/ 25-50mW VTX & ELRS RX

iFlight Blitz F411 1S 5A Toothpick/Whoop Flight Controller w/ 25-50mW VTX & ELRS RX

Regular price $83.99
Sale price $83.99 Regular price
In stock
In stock
Add To Wishlist
View full details

Details

Description

iFlight Blitz F411 1S 5A Toothpick/Whoop Flight Controller w/ 25-50mW VTX & ELRS RX is perfect for all of your lightweight builds. It is a Flight Controller, ESC, Receiver and VTX all in one little board weighing in at 4.8g. Now using ExpressLRS with a built-in ELRS ceramic antenna!

Check out all our whoop flight controllers, and all our iFlight Products!

Specifications

  • Input Voltage:  1S
  • MCU: STM32F411
  • Gyro: BMI270
  • Built-in Receiver: SPI ExpressLRS 2.4G
  • Receiver antenna: 2.4GHz SMD ceramic antenna
  • VTX: PIT/25/50mW
  • FC Firmware: IFLIGHT_BLITZ_F411RX
  • Current: 5A continuous and peak 6A (3 seconds)
  • Signal Support: Dshot, Oneshot, Multishot
  • ESC Firmware: O-H-30 BLS 16.8 (Supports BLHeliSuite)
  • Dimensions: 29x29mm, compatible w/ standard whoop framest
  • Weight: 4.8g

Includes

  • iFlight Blitz F411 1S 5A Whoop Flight Controller w/ 25-50mW VTX & ELRS RX
  • 4x M2 Rubber Damper
  • 1x Whip antenna

Wiring Diagram



More Info

  • SKU: 19437
  • Barcode: 691023522572


Overall rating: 3.2727273 / 5 from 11 reviews.

AI Generated Review Summary

Summary topics

Review topics: [].

Review highlights

Reviews

it does what it is

"it does what it is supposed to"

richard m. (4/5)

Hit and Miss

"This FC is a pain to bind. Once bound, it will lose it almost instantly. Or something else is causing ti to reset itself constantly. I've given up on this and anything iFlight as they are less than helpful. I've not had this amount of issues with other vendors, well except for three other vendors/mfgs."

Matthew R. (1/5)

Not a fan

"The controller is weird. Returned it after issues. Support from IFlight and rdq was great."

shawn t. (2/5)

"This thing didn't last 10 flights. Flew like garbage right out of the box. Won't even hook up to betaflight. I want my money back."

Jeffrey (1/5)

"So these are awesome for racing... If you are willing to deal with a couple things. When using these for racing, we generally remove the vtx and add a pro32nano below the FC. It's pretty dang hard to unsolder that vtx with those pins. The entire board is done with what seems like lead free solder, so it makes it difficult to work with. Same with the motor plugs. Make sure you have good solder and a really large solder tip if you want to swap the vtx. Iflight also didn't really give good, large pads to solder motor wires too, but it can still be done after removing the prigs. Again, add your own solder because the lead free stuff that is on the pads, sucks."

Nicholas (5/5)

Smoked

"Made smoke first time I connected it"

Wesley M. (1/5)

Perfect replacement

"When nothing else is available, you go with what you can get. The Blitz has been awesome so far!!"

Kris M. (5/5)

i worked through binding issues

"i now have it working with betaflight4.4 and elrs 3.01. on a fractal 65 frame. find the custom hex made by phobos"

corey (5/5)

Lots of power

"Tons of fun in a tiny package. I replaced the board in my NBD hummingbird f4 pro with this Little fella. Like night and day."

Shawn M. (5/5)

Best reveiw ever!

"Can't bind spi_rx crap that has only seen the product is not a legitimate review. And it's painfully obvious that this individual works in the distribution of the product and its bad business. You just called out the customers who spend a lot of money on this hobby. 1st, the diff all doesn't match the board name that's advertised. 2nd, it doesn't accept a binding phrase. 3rd, if I distributed a product and 1 of my employees left a review like this, He would most likely be looking for a new gig."

Chris B. (2/5)

Q&A
