Description

The iFlight Skyviz Goggles bring a fresh mecha-inspired design to FPV, combining style with advanced performance. Featuring dual 100Hz Micro-OLED displays and a precision 7-element lens system, they deliver smooth, crystal-clear visuals without distortion or screen-door effect. With an integrated fusion receiver, foldable antennas, and support for VRX, AV, and HDMI input, the Skyviz Goggles are both versatile and compact. Comfort-focused with adjustable diopters, IPD tuning, customizable LED colors, and intuitive controls, they’re built for immersive flying sessions with maximum usability.

Check out the rest of our FPV goggles and accessories, as well as our iFlight Products!

Features

• Built-in fusion receiver with foldable antennas
• DVR recording & playback with image adjustments
• Comfort fan control + customizable LED colors
• Sharp 7-element aspherical lens system
• Supports VRX, AV, and HDMI inputs
• Dual 100Hz Micro-OLED displays
• Custom FOV modes
• Analog FPV Goggles
• Adjustable diopter

Specifications

• Product Name: Skyviz Analog Goggles
• Weight: Approx. 300grams（headband included）
• Dimensions (L×W×H): L174.5 x W101.6 x H69.5mm (Antenna folding)
• Screen Size (single screen): 0.49-inch
• Resolution (single screen): 1920×1080
• Refresh Rate: 100 Hz(Max)
• Interpupillary Distance Range: 56-72 mm
• Diopter Adjustment Range: -7.0 D to +2.0 D
• FOV (single screen): 44°
• Aspect Ratio: 16:9/4:3
• Receiver: Built-in receiver
• Language: Chinese and English
• Power interface: DC4.5
• HDMI-IN: Micro HDMI
• AV-IN 3.5mm
• Headphone jack: /
• DVR format: MP4
• DVR frame rate: 30FPS (CVBS)
• Antenna: Omnidirectional linear polarization antenna
• Operating Temperature Range: -10°C to 40°C (14°F to 104°F)
• Power Input: 2-6S
• Supported SD Cards: microSD (up to 64 GB)

Includes

• 1x iFlight Skyviz Goggles
