JHEMCU GF30F745 3-6S HD 30x30 Flight Controller - MPU6000

Description

The JHEMCU GF30F745 3-6S 30x30 Flight Controller is ideal for drone pilots who demand high performance. It supports 3-6S and features advanced MPU6000 capabilities for smoother and more accurate flight. Enjoy an improved flying experience with this intuitive and reliable flight controller. Coming within 6pin plug in port designed for HD VTXs like the DJI O3 Air Unit.

Check out our other 30x30 FCs, and the rest of our JHEMCU selection!

Specifications

• Chip: STM32F745VG(216MHZ)

• Gyro: MPU6000

• Barometer: DPS310

• OSD Chip: AT7456E

• Black box: 16MM

• LED Program: Support

• BB buzzer: Support

• Input voltage: 3-6S

• I2C Connector: Support

• BEC: 5V/2.5A

• BEC: 10V/2.0A

• Cam Input: Support

• USART: UART1,UART2.UART3.UART4.UART6.UART7

• Receiver: ELRS(CRSF).TBS(CRSF).SBUS.IBUS.DSM2.DSMX

• GPS: YES

• COMPASS: YES

• HD O3: YES

• ESC Signal: Dshoot150.Dshot300,Dshot600

• USB: TYPE-C

• Current Port: Yes.

• Voltage Sensor: Yes

• DFU Button: YES

• FC firmware: betaflight_4.4.2_JHEF745.HEX

• Instal hole: 30.5x30.5x4MM

• Board size: 36x36MM

• Weight: 7.5g

Includes

• 1x JHEMCU GF30F745 3-6S 30x30 Flight Controller - MPU6000
• 4x grommets
