NewBeeDrone BeeBrain BLV3 AIO 1S Whoop Flight Controller (F4 FC / 12A 4in1 ESC / 5-120mW VTX) - Frsky

$99.99
In Stock
Pre Order
Coming Soon
Free Delivery on U.S.A. Orders $99 or more
Add to Wishlist

The BeeBrain BLV3 Flight Controller Flight Controller!

The latest iteration of the BeeBrainBL contains massive improvements to the performance of the built-in FrSky Receiver and built-in video transmitter.

In addition, the MOSFETs were upgraded to support the power demands of micro toothpick drones.

The solder pads on each ESC were enlarged to enable custom builds! With plenty of surface area and spacing, you can now solder on any motor of your choosing. One of our favorite applications of the BeeBrain BL is micro drones. Since the BeeBrain BL integrates the flight controller, ESCs, receiver, and video transmitter all in one package, it's insanely easy and clean to build.

Receiver Improvements - 50% More Range

  • Optimized SPI Receiver hardware to improve efficiency within the receiver.
  • Removable antennas.
  • Additional low noise amplifier to increase range. An optional wiring harness is included to install an external receiver (Crossfire, Ghost, etc)

Video Transmitter Improvements - 120mW

  • New heatsink and layout to increase heat dispersion and efficiency.
  • Transmitting power increased to 120mW from 25mW (V2)

Check out all our NewBeeDrone products!

Specifications

  • MCU: STM32F411
  • IMU: BMI270
  • OSD: Betaflight OSD w/ AT7456Ev
  • UART Ports: UART2 TX and RX are free for an external receiver
  • USB: Micro USB
  • Continuous current: 12A
  • MAX current: 15A (10s)
  • Input: 1-2S
  • Supports: Dshot600, Oneshot, Multishot
  • Target: Ships with JESC 48 KHz. BLHeli_s capable.
  • Size: Outer dimensions 29 x 29 x 7.6 mm
  • Installing Hole: 25.5 x 25.5 mm
  • Weight: 6g

Includes

  • 1x NewBeeDrone BeeBrain BLV3 AIO 1S Flight Controller - Frsky
