Details
Description
Building upon the success of the popular M10Q version, the NewBeeDrone BeeID Pro M10 GPS Module is specifically engineered for professional-grade drones and autonomous flight missions. This comprehensive navigation powerhouse has been fully optimized for PX4 series and other professional flight controllers. The integrated high-precision IST8310 compass and upgraded interface make wiring and configuration for professional rigs more reliable than ever.
Check out our GPS selection and the rest of our NewBeeDrone products.
- Standard GH1.25 6-Pin connector - compatible with PX4, ArduPilot, and other professional flight controllers
- High-performance IST8310 magnetometer provides exceptionally accurate heading data
- Supports concurrent reception of multiple GNSS (GPS, Galileo, GLONASS, BeiDou) for faster satellite acquisition and outstanding accuracy
- Built-in FAA-compliant remote ID
- Compact & Versatile
Specifications
- GPS Module: U-blox M10
- Compass (Magnetometer): IST8310
- Weight: ~ 13.37g
- Remote ID: Supported (WiFi / Bluetooth broadcast, FAA Compliant)
- Barometer: Built-in Broadcast Barometer (dedicated to Remote ID altitude data)
- Connector Type: GH1.25 6-Pin (Direct solder pads also available on the bottom)
- Input Voltage: 5V
- Size: 25 × 31.22 × 9.5 mm
Links
More Info
- SKU: G24867CN1Z
- Barcode: 723326381041
