NewBeeDrone Smoov V2 2306.5 1750Kv Motor

Original price $24.99
Original price $24.99 - Original price $24.99
Original price $24.99
Current price $16.99
$16.99 - $16.99
Current price $16.99
Coming Soon
In Stock
Pre Order
Free Delivery on U.S.A. Orders $99 or more

Add To Wishlist

Ring Magnets for an FPV drone? Yes! Team NewBeeDrone put in countless hours to figure out how they could improve upon the Smoov-Certified freestyle motor which provides super smooth performance for freestyle and cinematic FPV while maintaining the durability and precision machining you've come to expect from NewBeeDrone. NBD are proud to say that we have done just that... again!

The NewBeeDrone Smoov V2 2306.5 1750Kv Motor has not only improved upon our very successful V1 motor, it is now 3 grams lighter! It's constructed with 7075 aluminum alloy unibell design for the best structural rigidity and comes with fully molded ring-style magnets.

Ring motors are also easier to clean than traditional motors. Unlike traditional square magnet motors, the Smoov ring magnets have no physical spacing between the magnets to allow for quick and easy removal of dirt, grime, or anything you can manage to get into them.

Making a fully molded ring magnet with high magnetic flux density is at the heart of the design. NBD has developed a ring magnet that can hold up to N48SH levels! Ring magnets are typically used in camera gimbals because they need to operate silky smooth. Traditional gimbal motors are super smooth but they lack punch and power. The Smoov V2 motors have both, along with improved balancing and better performance. The Smoov V2 ring magnet motors have more punch, less weight, higher strength, and they're Smoover than ever!

This motor is also available in 2450Kv!

Check out our vast brushless motors selection, and all our NewBeeDrone products!


  • Single-winding with 0.15mm lamination stator.
  • Ring Magnet N48SH NdFeB V2
  • Super Smoov performance for freestyle and cinematic purpose
  • Japanese NSK Bearing
  • 7075 Aluminum
  • 6" prop compatible with Motor Limit Settings in BetaFlight


  • Input Voltage: 6S
  • Stator Diameter: 23mm
  • Stator Height: 6.5mm
  • Shaft Diameter: 5mm
  • Motor Dimension (Dia.*Len): Ø29.4mm*31.6mm
  • Weight: 36g(include cable)
  • Wire Size: 20AWG 150mm
  • Bearing: NSK/NMB 684ZZ  Ø9×Ø4×L4mm


  • 1x NewBeeDrone Smoov V2 2306.5 1750Kv Motor
  • 1x Hardware Pack
