SkyStarsRC Fly Stack F405 HD2 3-6S 30x30 Stack/Combo (F405 FC / KO50A 8Bit 50A 4in1 ESC)

SkyStarsRC Fly Stack F405 HD2 3-6S 30x30 Stack/Combo (F405 FC / KO50A 8Bit 50A 4in1 ESC)

$77.99
$77.99
In stock
In stock
Add To Wishlist
View full details

Details

Description

The SkyStarsRC Fly Stack F405 HD2 stack is an excellent choice for power-hungry pilots. Its F405 flight controller and KO50 8-bit 50A 4-in-1 ESC provide reliable, consistent performance, while its 3- to 6-cell battery supports power delivery up to 50 amps. Its 30x30 stack is perfect for professional-level pilots who need reliable, efficient power.

Check out our other 30x30 Stacks, and our SkyStarsRC collection!

    Specifications

    SkyStarsRC F4 Flight Controller

    • MCU: STM32F405
    • IMU: BMI270
    • OSD: AT7456E
    • Blackbox: 16MB
    • 6X Uarts(1 2 3 4 5 6)
    • WS2812 led Strip: YES
    • Baro: YES
    • Beeper: YES
    • BEC: 5V/2A,3A Peak
    • Betaflight FC Target: SKYSTARSF405
    • INAV FC Target:SKYSTARSF405HD
    • Mounting: 30.5x30.5mm, 4mm with Grommets 3mm
    • Dimensions: 36x36mm
    • Weight: 6g

    K050 50A 4in1 ESC

    • Dimension: 41x46mm
    • Mounting Holes: 30.5x30.5mm/¦µ3mm
    • Weight:13.3g
    • Supports 3-6S Lipo input
    • BB21 MCU, 48Mhz Runs BLHELI 16.X Firmware, Support Bulejay.
    • Current sensor: YES
    • BEC: NO
    • Supports: DShot DShot150/300/600/MultiShot/ OneShot etc.
    • Target: Q-H-50 BLS 16.7

    Includes

    • 1x SkyStarsRC Fly Stack F405 HD2 3-6S 30x30 Stack/Combo (F405 FC / KO50A 8Bit 50A 4in1 ESC)
    • 4x Damping Rubbers (M3x3.5mm)
    • 1x XT60 connector and wires
    • 2x 8pin wiring harness (1x 70mm,1x 50mm)
    • 1x 35v 560uf Capacitor

    Wiring Diagram

    More Info

    • SKU: 21069
    • Barcode: 691023446618


    Overall rating: 5.0 / 5 from 5 reviews.

    AI Generated Review Summary

    Summary topics

    Review topics: ["stack"].

    Review highlights

    Reviews

    Pretty sweet and clean stack

    "Pretty sweet stack for the price. FYI if you want to flash latest firmware, for the correct target, make sure you choose SKYSTARSF405PRO, every website and here suggest the target is is SKYSTARSF405 and for some reason the stamp on FC says HD 4, sooo idk. it works, diagram is clear, many many pads. If you flash wrong firmware it won't fully boot up, good luck! Paired with axis flying 2306. 5, flies like a dream"

    — Surge H. (5/5)

    Great stack

    "Great stack"

    — Chris A. (5/5)

    Great stack with all the

    "Great stack with all the Uarts youll need."

    — Joseph R. (5/5)

    Great Stack

    "Worked really well right out of the box I expect a lot of time with this stack."

    — texas f. (5/5)

    Awesome sauce

    "Awesome"

    — Travis H. (5/5)
