Description

Due to this item’s size or weight, it is not available for free shipping and may be shipped via ground.

The Caipirinha II is based on the Wipeout by HappyFlyers from Switzerland! A polycarbonate battery bay, push-to-open equipment bays, a PDB with up to 3 battery inputs, wiring channels that stretch across the entire wing, a huge 6mm-plywood-lined center section are just some of the innovations that make this plane stand out from the rest. An ultra-sleek and aerodynamic finish ensure that no energy goes to waste, and a very good glide slope makes thermaling or long distance slopeing highly enjoyable.

The PNP kit from TBS is equipped with high quality, digital metal gear servos, a CP2814-1150kV Cobra motor, 50A HobbyWing ESC and high quality Aeronaut CAM Carbon folding propellers. Vertical climbs, rocket-like punch outs, or highly efficient cruising are all within the design parameters of this setup!

We can confidently say it's going to be the only long range cruiser you will ever need, and the only flying wing in its weight class with such a performance envelope.

We also sell this wing without the FPV system, for line of sight flying, or adding your own custom FPV setup.

Check out all our PNP wings, as well as our TBS Products!

Features

• Small, lightweight, fly anywhere design

• Ultimate in flight stability and endurance

• Virtually indestructible EPP/Plywood construction

• Pre-cut camera, servo, battery, R/C receiver and video transmitter slots

• 2x push-to-open equipment bays for R/C and FPV electronics

• Pre-cut, sanded and covered ultra-lightweight elevons & pushrods

Specifications

• 36.5in / 93cm wingspan!

• 50oz / 1400g AUW (including GoPro Session5 and battery)

• 90min flying time

• 45mi / 75km endurance

• Battery (4S):

  • Capacity: 4500mAh 4S - 6600mAh 4S, 20C or more

  • SUGGESTED Dimension: 48 x 36 x 150 mm, 525g

  • MAX Dimension: 60 x 44 x 165 mm, 550g

Recommended FPV and Radio Equipment

• FPV camera: TBS ZeroZero II or TBS69

• Video transmission:

  • 5.8GHz: TBS FPVision or TBS UNIFY PRO V3 with TBS CORE PRO

  • 2.4GHz: TBS CORE PRO with Unify 500mW / 800mW VTx

• Crossfire Micro Rx or Diversity Rx
  Preliminary Manual (for experts only):
  • Lay out electronics (dry-fit)

  • Glue wing halves together

  • Set up radio gear and electronics

  • Set elevon travel +8mm, -6mm

  • AIL EXPO 60%, ELE EXPO 50%

  • Mount propeller

  • Check CG (bump near 30.5mm cutouts)

  • Fly, Crash, Repair, Repeat!

Includes

• 1xTBS Caipirinha 2 PNP FPV Flying Wing
• 1x hardware accessories

• 2x Digital MG Servo 6kgf/cm, 5-6V

• 1x CP2814-1050kV Cobra Motor

• 1x 50A HobbyWing Skywalker Wing ESC

• 1x Aeronaut 10x6 folding prop with prop assembly (CNC aluminum)
  Everything prepared as far as possible. Final assembly time around 2 hours
