ToolkitRC Q4AC 100W 5A Quad Channel 2-4S Smart Charger - XT60

ToolkitRC Q4AC 100W 5A Quad Channel 2-4S Smart Charger - XT60

$101.99
$101.99
In stock
In stock
Add To Wishlist
View full details

Details

Description

ToolkitRC's new AC/DC 4 channel charger operates on an internal 100W AC power supply or up to 200W on DC power! Other features include a bright 3.5" color display with a wide viewing angle, a metal scroll wheel, and the solid ToolkitRC build quality you expect!

Check out our other ToolkitRC offerings, as well as the rest of our chargers.

Features

  • AC or DC input
  • Up to 4 channels
  • Wide view screen
  • 32bit processor
  • Multiple language support

Specifications

  • Input Voltage: AC100-240V@MAX1.5A, DC10-18V@MAX20A
  • Supported Battery Type: LiPo LiHV LiFe Lion@1-4S, NiMh @1-10S, Pb @1-8S
  • Balance Current: 240mA @2-4S
  • Balance Accuracy: < 0.005V
  • Charge Power: 0.1-5A@50W*4 DC IN, 0.1-5A@50W*2 AC IN, 0.1-5A@25W*4 AC IN
  • Discharge Power: 0.1-2A@5W*4
  • Voltage Range: 0.2V-5.0V @1-4S
  • Internal Resistance: 1-100mR @1-4S
  • MicroUSB: Upgrade@USB2.0
  • Dimensions: 150x112x36.5mm
  • Weight: 600g
  • LCD: IPS 3.5 寸480*320 pixel

Manual

    Includes

    • 1x ToolkitRC Q4AC 100W 5A Quad Channel 2-4S Smart Charger

    More Info

    • SKU: 18189
    • Barcode: 6972969830179


    Overall rating: 4.3333335 / 5 from 15 reviews.

    AI Generated Review Summary

    Summary topics

    Review topics: [charger, power, battery, works, interface, fan, pins].

    Review highlights

    Reviews

    Best 4S compact-ish charger

    "This charger is amazing and has the ability to charge all sorts of different battery types, not just cell count. Very intuitive and great interface. My favorite charger to use. I wish the popular 1S charger was like this in terms of interface and options."

    — Ernesto A. (5/5)

    Works well for what it is

    "This charger works great for smaller type batteries that are 4S or less. Really easy to set up to charge/discharge/storecharge. the Fan can get alittle noisy when it turns on but it keeps the charger cool which is always important. Would recommend."

    — Carlos M. (5/5)

    Great little charger.

    "This is a great charger. Works well with my 3s2200s. I like that it tells you how much voltage is in each of the cells immediately when you plug it in. I does need balance wire extensions to be able to easily plug in 4 batteries at the same time."

    — Andrew C. (5/5)

    Great Charger, but ....

    "So I bought this charger from GetFpv and it has been wonderful. It has dramatically reduced my charge time, and I no longer have to spend hours watching a charger. My maximum battery size is 3s 2200, and I can almost apply maximum charge to 4 batteries at once. I have 6 2200 that I need to charge so I actually charge them 3 at a time with no problems. It is in the specs that we do have a bit of a limitation. Do check the spec; on charge you are limited to 100W in total on AC, 25 per channel, so I can't apply full charge on 4 2200s, but the issue is discharging, here you are limited to 20W, 5W per channel, this is a slow discharge, very slow. Now I am fine with this, hence no deductions. Finally, bit shout out to GetFpv for helping me understand this limitation."

    — John (5/5)

    Please send me atraps

    "Did t receive any straps"

    — eric b. (5/5)

    Good charger.

    "Good charger so far. I think this will be great for my 2 and 3s packs."

    — Matthew M. (4/5)

    Really nice, but not quite perfect

    "So my criteria was: - ability to charge more than 2+ batteries at once, ideally 4 - control charge current down to at least 0.2A - (ideally) AC-powered without having to buy a separate AC-DC power supply This checked all the boxes... and in fact was the ONLY charge I could find that did. So I ordered it. It seems to work well, but here's why it's not 5 stars: 1) The connector for the balance wires is ridiculously loose. If you plug it in and get contact, DON'T TOUCH IT. This makes managing multiple batteries tricky. 2) I wish it had more features besides just charge and discharge. Like various battery diags/tests. 3) Mine came with firmware v2.00 but I saw there was a 2.02 with a bunch of important fixes. The steps to flash are simple but over and over it wouldn't power on afterwards. Sometimes I get a fast fan, sometimes a slow fan, sometimes no fan. But nothing on the display. I even contacted ToolkitRC tech support. Ultimately it took just trying over and over again until it worked but there's definitely something wonky with the flashing process. Luckily I don't see needing to have to do it often but it was days before I could actually use it after I got it and I was afraid I bricked it."

    — Scott (4/5)

    Weak balance connectors

    "Charger works as it should but the balance connectors do not have long enough pins to batteries do not stay connected. Have to prop up the battery to make them stay in. Also when storage charging the display says discharging. would prefer it say storage or something like that. The current indicator shows + or - to show charging or discharging. So there is no difference in the indication when you are storage charging compared to discharging."

    — Bruce k. (3/5)

    Great little charger

    "This charger is small, but loaded with impressive features and price point. It is easy to operate. The display is very bright and shows the charging status of each battery as well as each cell. The only issue is that the power wires and balance wires are not the same length. Since this charger is so small the batteries become crowded at an odd angle when three or more are being charged simultaneously. I solved this issue by adding balance wire extender cables, to each port, which allow the batteries to be arranged parallel to each other and easily connected and disconnected without disturbing other batteries."

    — Robert S. (5/5)

    Bad luck or poor design?

    "This was my second Q4AC and it has the same issue as the first one I bought. The roller wheel doesn't move correctly when rotating to the left. It sometimes moves appropriately, but other times it moves the opposite way or not at all. Two for two with the same problem. I don't think it's me."

    — Chad S. (2/5)
