BetaFPV BNF Beta65X 2S Brushless Whoop Micro Quadcopter - FRSKY, DSMX, FLYSKY, PNP
- With the high performance STM32F405 processor FC boards and tuned Betaflight Ominibus 3.5.0 firmware, everyone could fly the Beta65X drone like a racing professor.
- Durable and light enough frame is customed for the Beta65X. A total weight of 26g give pilots a good balance of weight and nice punch on 2S battery.
- Whole drone no soldering or tinkering necessary. Customed lightest 0802 17500KV motors with cable connectors. Just plug and play.
- 2pcs 1S 260mAh Lipo HV batteries are recommended in default. So pilot could also use their whoop batteries.
- Weight: 26g (without battery)
- Motors: 0802 17500KV with connector
- Props: 31mm 4-blades props, 1.0mm shaft hole
- Camera: Z02 AIO Camera 35 degree
- Receiver Option: Frsky XM / FullSpeed DSMX / Flysky
- Batteries: 260mAh 1S Lipo HV batteries
- CPU: STM32F405
- Six-Axis: MPU6000
- Size: 26mm x 26mm, whoop mounting pattern
- Firmware version: Betaflight OMNIBUSF4SD (OBSD) 3.5.0
- OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)
- Smart Audio port is available for radio control VTX
- Support BLheli/BLHELI_S suite Pass-through ready
- Dshot600 in default
- Input voltage: 2S lipo
- Cotinue current: 6A
- Peak current: 10A
- Firmware: BLHELI_S
- Processor: SILABS EFM8BB21F16G
Z02 AIO Camera VTX
- Output power: 0mW, 25mW and 200mW (Adjustable)
- Smart Audio function is included for radio control
- Antenna: Dipole ANT
- Frequency: 5.8GHz 6 bands 48 channels, with Raceband: 5362~5945MHz
- TV System: NTSC
- Field of view: 100-120 degrees with 1/4 lens
The Beta65X drone comes with "props out" in default. Why we need "props out" direction?
Default Betaflight props direction, quadcopter dips and "washes out" in hard corners. With reversed props or "props out", no more dipping even in hardest cornering.
CUSTOM Z02 AIO Camera VTX
The AIO camera VTX on the Beta75X is a customed version of Z02. The VTX board and camera board are split and 35 degree camera mount for more fast flying. At the same time, it have all the other function of the Z02 camera, like output power switchable between 0mW, 25mW and 200mW. Smart audio is available for VTX remote control in default.
How to change the frequncy or output power via remont control, please check the manual Smart Audio.
Download the STL file for the camera mount.
1. About the LED at the rear for Beta75X
For the moment, the FC board doesn't support programable LED like WS2812 etc. The LED holder is designed on the frame nowadays. So we will update the FC board on the next version and release the suitable LED board.
Note: there is NO rear LED holder for Beta65X in default.
2. I am interested in connecting an HD camera and DVR, but I don't want to overload the circuit of 5V.
The 5V regulator on the FC board could handle 2A of load. So you could use it for HD camera or DVR board. More details, please check the FC board page.
3. Does this drone have current sensor?
This drone does NOT have a real current sensor. We use the virtual current meter in Betaflight. When properly calibrated, it can be accurate enough to be useful. Here is the pre-calibrated value out of the box.
set current_meter = VIRTUAL
set ibatv_scale = 90
set ibatv_offset = 29
4. How to connect the receiver to the 2S brushless FC?
Please don't forget to plug the battery when you try to connect the connector to the 2S brushless FC. Find out more details in our support page.
5. Cli Dump for different versions of the 2S Whoop are provided in our support page.
- 1 * Beta65X BNF 2S Whoop Quadcopter
- 1 * Spare 31mm 4-blades props (2CW+2CCW)
- 2 * 260mAh 1S Lipo HV batteries (Not for PNP version)
- 1 * Spare Canopy
