BetaFPV M01 V2.1 Micro AIO 700TVL FPV Camera & 25mW VTX (Pin-Connected Version) w/ Canopy

$28.99
In Stock
Pre Order
Coming Soon
Add to Wishlist
Free Delivery on U.S.A. Orders $50 or more

M01 AIO Camera 5.8G VTX comes with a super Mini 5.8GHz FPV Transmitter + 600TVL FPV Camera + RG178 Antenna, features 6 bands and 37 channels on the 5.8GHz band with Raceband. The unit is ultra-lightweight and pins connect with FC, so it is easy to place on Pro Series and Brushed Whoop Drone.

V2.1 now has a wiring harness connection for the camera and a u.Fl VTX antenna connector

 Check out all our Camera/VTX AIOs & Combos, and our BetaFPV gear!

Features

  • Wiring harness for camera
  • u.Fl VTX antenna connector
  • Pins connect with FC, easily Installation
  • Lighter than Z02 AIO Camera, perfect for Micro Drone
  • Suitable for Pro Series and Brushed Whoop Drone
  • 25° and 35° Camera tilt Mount are provided to suit your preference.

Specifications

  • Item: Z02 Cam
  • TVL: 600TVL
  • FOV: H:120°/V:100°
  • Video System: NTSC
  • Horizontal Resolution: 640X480 1/4”
  • Output power: 25mW
  • Supply Voltage: 5V
  • Size: 18*14*4.5mm(VTX)
  • Weight: 3g
  • Antenna: RG178 Antenna
  • Frequency: 5.8GHz 6 bands 37 channels, with Raceband: 5362~5945MHz


Includes

  • 1x BetaFPV M01 V2.1 Micro AIO 700TVL FPV Camera & 25mW VTX (Pin-Connected Version) w/ Canopy


Wiring Diagram

The following diagram describes the organization and wiring of the physical components on M01 VTX V2.1 board.

How to Connect with FC
