Diatone Mamba Basic F722 MK3 30x30 3-6S Stack/Combo (F722 FC / 50A 4in1 ESC)

$93.00
In Stock
Pre Order
Coming Soon
Free Delivery on U.S.A. Orders $60 or more
Add to Wishlist

This stack pairs the Mamba Basic F722 MK3 FC and the Mamba F50 50A 4in1 ESC. With multiple UARTS and BECS, this stack can run all the peripherals you could ever want with ease.

Browse our Stacks & Combos and our Diatone Gear!

Features

  • I2C function
  • LED controller
  • Multiple BECs
  • Large solder pads
  • BEC short circuit protection
  • TVS instant high voltage protection 30V
  • 6 UARTS
  • 50A ESC
  • Only 31g

Specifications

Diatone Basic F722 MK3 Flight Controller

  • MCU: 216MHz STM32F722RET6
  • GYRO: MPU6000
  • Barometer: Yes
  • OSD: Yes
  • Blackbox: 16M Flash Memory
  • Uarts: 6Set
  • ESC Soft: Dshot300/600
  • ESC Telemetry: Yes
  • Power Led: Yes
  • LED Controller: BF LED/MB LED(4 Set 2812 LED)
  • S/F.Port: Yes
  • RSSI: Yes
  • Buzz: Yes
  • Input: 3~6S Lipo (12.6~25.2V)
  • TVS Protection: Yes
  • BEC: 3.3V/0.5A, 5V/3A (System Power), 5V/3A(LED), & 9V/3A
  • Mounting: 30.5x30.5mm, M3
    Diatone Mamba F50 4in1 ESC
    • Input Voltage: 3~6S Lipo (12.6V~25.2V)
    • Continuous Current : 50A×4
    • Burst Current: 55A (10S)
    • BEC: No
    • Target:BLHeli_S CH40
    • Soft: Dshot300/600
    • TVS Protection: Yes
    • Mounting: 30.5mm/M3

      Includes

      • 1x Diatone Mamba Basic F722 MK3 30x30 3-6S Stack/Combo (F722 FC, 50A ESC)

      Manual Download
