iFlight Succex-D F7 TwinG & 50A 32Bit 4in1 ESC 30x30 Stack/Combo for DJI

$95.99
In Stock
Pre Order
Coming Soon
Add to Wishlist

The SucceX-D F7 TwinG 50A Stack is designed to work seamlessly with DJI’s new HD FPV system. To make things as simple as possible, we have included a connector specifically for the DJI air unit, so installation should be a breeze. In addition, we add the popular and reliable USB Type-C instead of Micro USB which makes the connection easily.

Check out the entire iFlight Succex-D Line as well as all our DJI Friendly Electronics, Frames and Accessories!

Features

FC

  • Universal USB Type C connector instead of micro USB
  • Plug-and-Play. No need to solder tiny wires.
  • Designed to support DJI Digital FPV.

ESC

  • 8 layer double-sided PCB
  • 4oz 1.6mm thick power board(0.9mm copper ratio),better operating load capacity
  • 32bit FO51K86 MCU, 48mHz maximum clock speed
  • TDK MLCC Low ESR ceramic capacitors
  • Top grade NTMFS5C430NL MOSFET
  • Rational layout, countersunk holes on extended solder pads to ensure PCB layer connection

Specifications

FC

  • Input voltage:2-6S,MAX 8S
  • MCU:216MHz STM32F722RET6
  • Gyro: 2x ICM20689
  • Baro:YES
  • Betaflight OSD:YES
  • Blackbox: 32MB
  • 5x Uarts
  • 8x Motor outputs
  • 8 pin 4in1 ESC port
  • 4 pin VTX connector
  • Dimensions: 36x36mm
  • Mounting Dimensions: 30.5x30.5mm, M3
  • Weight: 7.5g
  • Firmware:betaflight_4.0.5_STM32F7X2.hex
  • CLI dump file:IFLIGHTF7_TWIN_G.config

ESC

  • Input Voltage: 2-6S
  • Dimension: 43*39mm
  • Mounting Holes: 30.5*30.5mm/Φ3mm
  • Weight:14.4g
  • STM32F051 MCU, 48Mhz Runs BLHELI 32.X Firmware
  • Current sensor: Yes
  • Telemetry:Supported
  • BEC: No
  • Supports: DShot DShot150/300/600/1200/MultiShot/ OneShot etc.
  • Target: iFlight-BL32-4IN1

    If you use your own DJI Remote Controller, you MUST update your firmware betaflight_4.1.0_STM32F7X2  configurator betaflight to 10.6.0 to set up and bind your DJI remote controller.

    • Model 1 setup:Reveiver tap -----> Choose “Spektrum / Graupner / JR (TAER1234)”
    • Model 2 setup:Reveiver tap -----> Choose “Frsky / Futaba / Hitec (AETR1234)”

    Downloads

    Includes

    • 1x SucceX-D F7 TwinG FC
    • 1x SucceX 50A BLHeli_32 4-in-1 ESC
