HolyBro Kakute F7 Mini V3 20x20 Flight Controller

$32.99
In Stock
Pre Order
Coming Soon
Free Delivery on U.S.A. Orders $60 or more
Add to Wishlist

Feature packed 20x20 FC from HolyBro.

Check out all our our Holybro products!

Specifications

  • MCU: STM32F722RET6 32-bit processor,216MHz, 256Kbytes RAM, 512Kbytes Flash
  • IMU: MPU6000 (SPI)
  • Lipo Input: 2-6S
  • Barometer: BMP280
  • USB VCP Driver (all UARTs usable simultaneously; USB does not take up a UART)
  • 5hardware UARTS (UART1,2,3,4,6)
  • Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only. PPM and PWM receivers are not supported.
  • Onboard 16Mbytes for Blackbox logging
  • 5V Power Out: 1.0A max
  • 3.3V Power Out: 0.2A max
  • Dimensions: 30x30mm
  • Mounting Holes: Standard 20mm square to center of holes
  • Weight: 4g

Includes

  • 1x HolyBro Kakute F7 Mini V3 20x20 Flight Controller
